Canoe Building Schematics & Plans Canoe Building Plans. All models of our Cedar Strip Epoxy canoe are available in plan form. The building plans are complete sets of of CAD rendered drawings. The cost for each plan is $69.95 CAD plus shipping and handling. In addition to the plans, we also make available full kits, including materials. Parts of a Boat (Illustrated Diagram of a Boat's Anatomy ... Parts of a boat explained. Bow: the front of a boat. Stern: the rear of a boat. Port: left side of a boat. Starboard: right side of a boat. Helm: the driver's seat. Gunwale: the top of the boat's side (upper edge). If water comes higher than the gunwale, it enters the boat. Transom: The cross-section of the rear of the boat (stern). Pilothouse: Enclosed cabin for driver and passengers.
